Custom Metal Slitting & Toll Processing

Copper - Aluminum - Steel - Painted Metals - Plastics

Copper - Aluminum - Steel - Painted Metals - Plastics

Copper - Aluminum - Steel - Painted Metals - Plastics Copper - Aluminum - Steel - Painted Metals - Plastics

Custom Slitting Capabilities

Coil slitting involves running flat rolled metal products through slitter heads composed of knives that cut and break metal into narrower widths. When coils reach the desired length, the coils are cut using shears. Coils are then carefully inspected for defects, recoiled and reworked to correct any incoming shape issues and defects using tension rolls on the slitter.

We specialize in custom processing & slitting of : Copper - Aluminum - Titanium - Galvanized Steel - Hot & Cold-Rolled - Stainless - Painted Metals - Plastics

  • Light to medium gauge (0.007 – 0.135 inches) 72-inch-wide Octagon slitter

  • Heavy-gauge (0.054 – 0.300 inches) 60-inch-wide Yoder slitter

State-of-the-Art Equipment

VAP Steel continuously reinvests in equipment & preventative maintenance to ensure highest quality processing, with significantly reduced lead-times for customers. We have two steel slitters: a light to medium gauge (0.007 – 0.185 inches) 72-inch-wide Octagon slitter, and heavy-gauge (0.054 – 0.300 inches) 60-inch-wide Yoder slitter.

Copper - Aluminum - Steel - Painted Metals - Plastics

Copper - Aluminum - Steel - Painted Metals - Plastics

Copper - Aluminum - Steel - Painted Metals - Plastics Copper - Aluminum - Steel - Painted Metals - Plastics

Light-to-Medium Gauge Slitting (Octagon Slitter):

  • Gauge: 0.007 - 0.185 inches

  • Width: 72 inch

  • Outer Diameter (OD) incoming: 80 “

  • Outer Diameter (OD) outgoing: 74.25 “

  • Max coil: 60,000 #

  • Inner Diameter (ID): 20-24 “

  • 40 ft deep looping pit

Heavy-Gauge Slitting (Yoder Slitter):

  • Gauge: 0.054 - 0.300 inches

  • Width: 60 inch

  • Outer Diameter (OD) Incoming:

  • Outer Diameter (OD) outgoing: 69 inch

  • Max Coil: 60,000 lbs

  • Inner Diameter (ID): cone mandrel system 16 – 32 inch

  • 25 ft deep looping pit

Additional Value-Added Services

    • Max Coil: 10,000 lbs

    • Outer Diameter (OD) incoming: 71 inch

    • OD outgoing: 69 inch

    • Inner Diameter (ID) incoming: 16 – 24 inch

    • ID Outgoing : 20-24 incht goes here

  • Packaging Line 1 (right)

    • 74 inch Outer Diameter Max

    • 10,000 lbs. Max Coil

    Packaging Line 2 (left)

    • 69 inch Outer Diameter Max

    • 6,200 lbs. Max Coil

  • Rockwell Hardness Testing: The Rockwell Test is an efficient and accurate hardness test method developed for quality control during production at VAP Steel. The test enables a fast and direct readout of the metal product hardness, which correlates directly with its strength, wear resistance, and other properties.
